Description
The YR01830 Benchtop TDS/Conductivity Meter is a cutting-edge device designed to provide precise measurements for a variety of parameters including conductivity, TDS, salinity, and resistivity. With a 5-inch LCD screen offering a 150° viewing angle, users can read measurements clearly even from a distance of 5 meters. Equipped with a built-in microprocessor chip, this meter boasts intelligent features such as automatic calibration, Automatic Temperature Compensation (ATC), data storage capability for 300 sets, and a clock display. Two USB interfaces facilitate easy data transfer and battery charging. Its top-notch conductivity measurement technology and capacity to switch between various measurement modes make it a versatile tool for laboratories and industrial settings alike.
Market Price
The YR01830 Benchtop TDS/Conductivity Meter is competitively priced within the market, with similar devices typically ranging from $800 to $1,700. This makes the YR01830 an excellent choice for those seeking high-end performance without exceeding budget constraints. Request a quote through Kalstein Plus to discover how you can secure this state-of-the-art meter at an attractive price.
Frequently Asked Questions
What is the battery life of the YR01830? The rechargeable battery lasts up to 30 hours and the device automatically powers off after 10 minutes of inactivity to conserve energy.
Can the YR01830 be used outdoors? Yes, with an IP54 rating, it is designed to withstand conditions with moderate humidity and dust.
Which electrodes are compatible with this meter? The YR01830 automatically recognizes various electrode types, enhancing convenience and efficiency.
Advantages and Disadvantages
The YR01830 offers numerous advantages, such as precise measurements, user-friendly interface, and versatile application across different settings. However, its initial setup may be slightly complex for those unfamiliar with advanced metering equipment.
Field Use
In practical scenarios, the YR01830 is instrumental for environmental monitoring, industrial quality control, and laboratory research. Its ability to deliver accurate conductivity and TDS measurements makes it an indispensable tool in these fields.
Recommendations
To maximize the longevity and performance of the YR01830, it is advisable to keep the device clean and regularly calibrate it using standard solutions. Utilizing the USB interface for data backup can ensure your measurements are securely stored.
Features
- 5-inch LCD screen for easy reading
- Automatic calibration and temperature compensation
- Data storage for up to 300 sets
- USB connectivity for data transfer
- Conductivity electrode with a constant of 0.1/1/10 cm-1
- IP54 rated for protection against dust and water
Technical Specifications
| Model | YR01830 | |
|
Conductivity
|
Measuring range
|
Conductivity: (0.00~20.00)μS/cm; (20.0~200.0)μS/cm; (200~2000)μS/cm; (2.00~20.00)mS/cm; (20.0~200.0)mS/cm |
| TDS: (0~100) g/L | ||
| Salinity:(0 ~ 100)ppt | ||
| Resistivity:(0 ~ 100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1mS/cm | |
| Accuracy | Meter: ±1.50% FS; Electrode: ±1.0% FS | |
| Temp. compensation range | (0 ~ 50)ºC , auto | |
| Electrode constant | 0.1 / 1 / 10 cm-1 | |
|
Temperature
|
Measuring range | (-10 ~ 110)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5~ 60ºC: range: ±0.5ºC; other range: ±1.0ºC | |
|
Other Technical Parameters
|
Display | 5-Inch white backlit LCD screen |
| Data storage | 300 sets | |
| Power | DC 5V/1A | |
| Communication connector | Micro USB & Standard USB | |
| Dimension/N.W. | 180 x 130 x 14mm/280g | |
|
Working Condition
|
Environment Temp. | 5 ~ 35 ºC |
| Environmental | ≤85% | |
| IP Grade | IP54 | |
