Description
The Portable Conductivity/DO Meter YR06382 is an advanced and versatile tool designed for precise measurement of conductivity, dissolved oxygen (DO), TDS, salinity, and resistivity. Equipped with a large LCD screen featuring controllable backlighting, this device is user-friendly, even in low-light conditions. The built-in microprocessor chip offers intelligent features such as automatic calibration, temperature compensation, data storage, and more, ensuring high accuracy and reliability in various analysis tasks.
Price in the Market
The Portable Conductivity/DO Meter YR06382 is competitively priced in the market. With prices ranging from approximately $700 to $1,000 USD, it offers excellent value for laboratories and fieldwork scenarios that demand accurate and quick conductivity and DO measurements.
Frequently Asked Questions
How long does the DO electrode take to polarize? The polarographic DO electrode has a short polarization time of just 3-5 minutes.
What type of batteries does the device use? The meter operates on two AA batteries (1.5V each), ensuring ease of replacement and extended operating time.
Advantages and Disadvantages
Advantages: The YR06382 meter provides multi-mode measurement capabilities (conductivity, TDS, salinity, DO, and resistivity), automatic temperature and salinity compensation, a compact design, and durable dustproof and waterproof construction (IP57).
Disadvantages: The manual pressure compensation could be seen as a limitation in fully automated settings, and the range of applicable temperatures might not cover every field scenario.
Field Use
This conductivity and DO meter is ideal for laboratories and environmental research where water quality needs regular testing. Its compact, portable design allows professionals to take field measurements in a variety of locations, providing vital data for water treatment assessments, aquatic life investigations, and more.
Recommendations
To maximize the efficiency of your YR06382, schedule regular calibration sessions, ensure your electrodes are clean and well-maintained, and always store the device in a dry, safe place to prolong its lifespan. Consider leveraging the Kalstein Plus platform for automatic quote generation to ensure you’re getting the best pricing for larger orders or if additional units are needed.
Key Features
- Large LCD screen with controllable backlight for optimal visibility.
- Intelligent functions including auto calibration and diagnosis.
- Measures conductivity, TDS, salinity, and resistivity with high accuracy.
- Polarographic DO electrode with short polarization time.
- Robust design: IP57 dustproof and waterproof rating.
- Data storage capability for up to 200 sets of records.
Technical Specifications
| Model | YR06382 | |
| Cond. | Measuring range | Conductivity: (0.00~19.99)μS/cm |
| (20.0~199.9)μS/cm | ||
| (200~1999)S/cm | ||
| (2.00~19.99)mS/cm | ||
| (20.0~199.9)mS/cm | ||
| TDS:(0~100)g/L | ||
| Salinity:(0~100)ppt | ||
| Resistivity:(0~100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1 mS/cm | |
| Accuracy | ±1.0% FS, Overall:±1.5% FS | |
| Temp. compensation | (0~100)ºC(Auto/manual) | |
| Electrode constant | 0.1 / 1 / 10 cm-1 | |
| DO | Measuring range | (0 ~ 20.00) mg/L(ppm), (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm), 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Instrument: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp. compensation | (0 ~ 45)ºC (auto) | |
| Salinity compensation | (0 ~ 45) ppt (auto) | |
| Pressure compensation | (66 ~ 200) kPa (manual) | |
| Auto calibration | Air saturated by water, water saturated by air | |
| Electrode type | Polarographic | |
| Temp. | Measuring range | (0 ~ 100)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
| Other | Data storage | 200 sets |
| Power | Two AA batteries (1.5V x2) | |
| Ambient Temp. | 5 ~ 35 ºC | |
| Ambient humidity | ≤85% | |
| IP grade | IP57 Dustproof and waterproof | |
| Dimensions/N.W. | (65×120×31)mm/180g | |
| Shipping size/G.W. | (460×300×55)mm/1Kg | |
