Benchtop Conductivity/DO Meter YR06384

Description

The Benchtop Conductivity/DO Meter YR06384 is a cutting-edge device designed for precise measurement of conductivity and dissolved oxygen (DO) in laboratory settings. This meter features a high-resolution 7-inch colored capacitive touch screen, allowing for intuitive operation and data visualization. Equipped with an intelligent microprocessor chip, it offers automatic calibration, data storage for up to 1000 sets of test data, and the ability to transfer data seamlessly through USB or Bluetooth connections. Its smart electrode status display ensures accurate and consistent usage, making this an essential tool for researchers and professionals who demand precision and reliability in their measurements.

Market Price

The average market price for a benchtop conductivity and DO meter with features comparable to the YR06384 ranges between $1,200 and $2,000. This product stands out for its accuracy and advanced data handling capabilities, justifying its position on the higher end of the price spectrum. To get a customized quote and more details about the benefits of this meter, we invite you to request a quotation via the Kalstein Plus platform.

Frequently Asked Questions

Q: Can this meter be calibrated automatically?
A: Yes, the YR06384 supports automatic calibration to ensure accuracy and ease of use.

Q: Is data transfer possible via Bluetooth?
A: Absolutely, real-time data transfer to your mobile device is an optional feature using Bluetooth technology.

Advantages and Disadvantages

Advantages: High accuracy, large data storage capacity, easy data transfer options, and user-friendly interface.

Disadvantages: Its advanced features may not be necessary for basic applications, potentially making it overqualified for simpler tasks.

Use of Product in the Field

The YR06384 is ideal for laboratories requiring precise conductivity and DO measurements. It’s widely used in applications ranging from environmental analysis to biochemical research, providing accurate and reliable data across various sample types.

Recommendations

For optimal results, regularly calibrate the electrodes and ensure the device is kept in an ideal environmental condition, avoiding areas with high dust or humidity. Regular software updates available through the manufacturer’s platform can enhance performance and add new functionalities.

Features

Conductivity range: 0.5μS/cm to 200mS/cm
Dissolved Oxygen (DO) range: 0 to 20.00 mg/L
Supports conversion to TDS, salinity, resistivity
10 different electrode constant options
Temperature range: (-10~110)ºC
Interactive 7-inch capacitive touch screen
Data transfer via USB, RS232, Bluetooth

Technical Specifications

Model		YR06384
Cond.	Measuring range	Conductivity:
		(0.00~20.00)μS/cm, (20.0~200.0)μS/cm
		(200~2000)μS/cm, (2.00~20.00)mS/cm
		(20.0~200.0)mS/cm,
		(200~2000)mS/cm (K=10)
		TDS:(0 ~ 100)g/L
		Salinity:(0 ~ 100)ppt
		Resistivity:(0 ~ 100)MΩ·cm
	Resolution	0.01/0.1/1μS/cm; 0.01/0.1mS/cm
	Accuracy	Electrode: ±0.5% FS, Meter: ±0.8% FS
	Temp. compensation range	(0 ~ 50)ºC, auto
	Electrode constant	0.1/0.5/1/5/10/50/100 cm-1
	Reference Temp.	25ºC,20ºC,18ºC
DO	Measuring range	(0 ~ 20.00)mg/L(ppm) (0 ~ 200.0)%
	Resolution	0.1/0.01 mg/L(ppm) 1/0.1 %
	Accuracy	Electrode: ±0.10 mg/L, Meter: ±0.40 mg/L
	Response time	≤30s (25ºC, 90%response)
	Residual current	≤0.1 mg/L
	Temp compensation	(0 ~ 45)ºC, auto
	Salinity compensation	(0 ~ 45) ppt, auto
	Pressure compensation	(80 ~ 105) kPa, auto
	Auto calibration	Air saturated by water; water saturated by air
	Electrode type	Polarographic
Temp.	Range	(-10 ~ 110)ºC
	Resolution	0.1ºC
	Accuracy	5 ~ 60ºC:±0.4ºC Others: ±0.8ºC
Other	Display	7-inch colored capacitive touch screen
	Data storage	1000 sets
	Power	12V/1A
	Output	USB, RS232, Bluetooth
	Ambient Temp.	15 ~ 30 ºC
	Ambient Humidity	≤85%
	IP grade	IP54
	Dimensions/N.W.	240×170×70mm/600g
	Shipping Size/G.W.	470x430x85mm/2.6kg

Additional information

Weight	3 kg
