Description
Convenient mobile diagnosis and treatment
Highly integrated design, compact size with stronger functions
4 sizes (0/1/2/3) imaging plates available
1.5kg lightweight
Mini-size and portable
5s faster imaging
Technical Specifications
| Model | YR06197 |
| Tube voltage | 60KV |
| Exposure time | 0.1~2s |
| Tube focus | 0.3mm ×0.3mm |
| Battery | DC14.8V 6400mAh |
| Charger input voltage | AC100V-240V:10% |
| Ambient temperature | 5-40℃ |
| Net weight | 2.5kg |
| Package size | 330 ×310×230 ( mm ) |
| Tube current | 1.5mA |
| Frequency | 30KHz |
| The distance from skin to cone | 130mm |
| Rated power | 60VA |
| Output voltage | DC16.8V |
| Relative humidity | <75> |
| Gross weight | 4.8kg |
