Series Density Balance YR06704//YR06704-4
Series Density Balance YR06704//YR06704-4 — equipo de laboratorio Kalstein con especificaciones técnicas, características avanzadas y soluciones profesionales certificadas para uso científico.
The YR06704//YR06704-4 series density balance is a high-precision instrument designed for the reliable determination of density in solids, liquids, powders, and absorbent materials. This instrument combines analytical weighing functions with automatic density calculation, making it a versatile solution for quality control laboratories, research, and the chemical, pharmaceutical, food, and materials industries. Depending on the model, it offers capacities from 210 g to 610 g , with readability ranging from 0.01 g to 0.001 g , ensuring accurate measurements even with small samples (minimum weighing from 0.004 g). Its system allows conversions between units of weight (g, ct, oz) and density (D, %, K), facilitating comparative analyses and standardized technical reports.
Design and technology (functionality)
The balance integrates a 160 x 70 mm weighing pan and a 139 x 100 x 78 mm immersion tank , optimized for hydrostatic testing. Its robust and stable structure minimizes vibrations and errors due to environmental interference within the 5–25 °C operating range. It includes a 200 g calibration weight , ensuring traceability and metrological accuracy. Repeatability (up to ±0.002 g in model YR06704-4) and linearity (up to ±0.003 g) position it as one of the best options on the market for quality control and materials analysis. In terms of price, density balances with these characteristics typically range from USD 1,800 to USD 4,500 on the international market , depending on the model, precision, and included accessories, making this series a competitive alternative in terms of cost-benefit ratio.Product use in the field
In real-world applications, the YR06704 Density Balance is used to evaluate materials such as plastics, rubbers, ceramics, light metals, resins, oils, solvents, and industrial powders. In quality control, it allows for verification of batch uniformity; in R&D, it supports the development of new materials; and in production, it helps detect early deviations in formulations. The typical procedure involves weighing the sample in air and then submerged in the reference liquid (usually distilled water), automatically obtaining the density without manual calculations.Frequently Asked Questions (FAQ)
Is it difficult to use?No. The equipment is designed with an intuitive interface and pre-configured modes for solids, liquids, and powders.Does it require specialized maintenance?Only periodic calibrations and basic cleaning of the tank and tray.Does it work with liquids other than water?Yes, it can be used with other reference fluids according to the applicable standard.Does it include accessories?It comes with a calibration weight and standard tank; additional accessories can be requested.Advantages and disadvantages
Advantages:- High precision and repeatability.
- Versatility for solids, liquids and powders.
- Automatic density calculation.
- Robust and stable construction.
- Wide range of capabilities depending on the model.
- Requires an environment with basic temperature control.
- It is not portable for extreme fieldwork.
- Higher initial investment than conventional scales without a density function.
Recommendations to maximize your performance
- Perform periodic calibration with the included weight.
- Keep the tank free of bubbles and debris.
- Avoid drafts and vibrations on the work table.
- Use distilled water or certified reference liquid.
- Record temperature conditions in each measurement for traceability.
Technical Specifications
| Model | YR06704 | YR06704-1 | YR06704-2 | YR06704-3 | YR06704-4 |
| Ability | 310g | 610g | 610g | 310g | 210g |
| Test mode / Test mode | Solid/Liquid | Absorption of solids/liquids/powders/water | |||
| Readability (or Reading Accuracy) | 0.01g | 0.01g | 0.005g | 0.001g | |
| Minimum weight | 0.04g | 0.04g | 0.020g | 0.004g | |
| Repeatability | ±0.02g | ±0.02g | ±0.010g | ±0.002g | |
| Linearity | ±0.03g | ±0.03g | ±0.015g | ±0.003g | |
| Unit conversion | weight:g/ct/oz density:D | weight:g/ct/oz density:D/%/K | |||
| Weighing plate size | 160x70mm | ||||
| Tank/reservoir size | 139x100x78mm | ||||
| Temperature | 5-25℃ | ||||
| Calibration weights | 200g | ||||
| Packaging size | 310x230x130mm | 440x310x300mmx2 | |||
| Gross weight | 4kg | 6kg | |||
Technical specifications
| Manufacturer | Kalstein |
|---|
