Nine - Point Magnetic Stirring Hot Plate for Laboratory YR02946
Nine - Point Magnetic Stirring Hot Plate for Laboratory YR02946 — Kalstein laboratory equipment with technical specifications, advanced features, and certified professional solutions for scientific use.
The Nine-Point Magnetic Stirring Hot Plate for Laboratory YR02946 is an essential tool for laboratories, particularly in the fields of chemistry and biology. This device is favored for its silent operation and efficiency, which surpasses that of gear-driven motorized stirrers. Its compact design allows for easy cleaning and sterilization without the need for lubricants, making it ideal for use in hermetically sealed systems. Equipped with a hot plate, it integrates heating functionalities to accommodate a variety of laboratory needs.
Market Price
Magnetic stirring hot plates generally range in price, depending on their complexity and features. The Nine-Point Magnetic Stirring Hot Plate for Laboratory YR02946 falls within a mid to high-range pricing category due to its advanced capabilities, robust design, and precision controls. On average, the price can vary from $500 to $700, though prices may differ based on suppliers and optional accessories.
Frequently Asked Questions
What is the maximum temperature it can reach? The hot plate's surface temperature can reach up to 350°C.
What is the capacity of this stirring hot plate? It handles 9 points, each capable of stirring up to 250ml.
How do I adjust the temperature and speed? It offers stepless voltage adjustment and digital display for precise control of temperature and speed.
Advantages and Disadvantages
The key advantages of this product include its compact size, digital display for easy monitoring, and heat-resistant materials. The use of an aluminum alloy and ceramic coatings ensures durability and efficiency. However, one potential downside could be its weight (9500g), which might be cumbersome for some users needing frequent device relocation.
Product Use in the Field
In practical situations, the Nine-Point Magnetic Stirring Hot Plate is invaluable for mixing and heating solutions in a controlled manner. It is used in experiments requiring precise thermal conditions and stirring speeds, such as chemical reactions, mixing of biological samples, and solution preparation.
Recommendations
For optimal performance, regularly clean the stirring hot plate and ensure the stirring bars are free of residues to prevent contamination. Avoid exceeding the maximum temperature and speed settings to maintain device longevity. Leverage the digital display for real-time monitoring and make adjustments as necessary to achieve desired results.
Features
- Very compact and easy to operate
- Digital display of temperature and speed, Heating temperature: Rt-380°C and mixing speed: 100-1800 RPM
- Heat and corrosion-resistant aluminum alloy housing for enhanced durability
- Ceramic-coated aluminum plate for excellent heat distribution and corrosion resistance
- Protective housing design to prevent spills from damaging electronics
- Additional heat insulation plate to minimize heat loss and protect electronic components
- Adjustable temperature and rotation speed
Technical Specifications
| Model | YR02946 |
| Temperature adjustable multipoint magnetic stirrer | |
| Specification | 9 points |
| Temperature | The surface temperature can be up to 350°C |
| Heating area | 280mm × 280mm |
| Power of heating | 750W |
| Temperature control type | Stepless voltage adjustable, 0~220V controlled silicon controlling |
| Presion of temperature controlling | ± 5°C |
| Heating wire | Cr20Ni80 |
| Material | TU2 red copper |
| Capacity | 9 points: 9×250ml |
| Power of the motor | 9×8W |
| Range of speed adjustment | 0-2000 rpm (digital display of speed) |
| Power supply | 220V 50HZ |
| Working time | Continuous |
| Overall dimension | 500 × 330 × 150mm |
| Packing dimension | 550 × 380 × 200mm |
| Weight | 9500 ± 200g |
Technical specifications
| Weight | 9 kg |
|---|---|
| Manufacturer | Kalstein |
