| Model |
YR05128 |
| Absorbance range |
0 – 4.000Abs |
| Resolution |
0.001 Abs (displayed), 0.0001 Abs (calculated) |
| Light source |
6V/19W halogen lamp |
| Optical system |
8-channel optical fiber system |
| Lengths |
4 standard filters wave: 405 nm, 450 nm, 492 nm, 630 nm, 3 additional optional filters |
| Wavelength accuracy |
2 nm |
| Bandwidth |
8 nm |
| Calculation method |
ABS, cut, multipercentage, percentile registry, linear. Exponential, Index, Regression 4PL, etc. |
| Methodologies |
Endpoint, Fixed time, Kinetics |
| Type |
Standard microplate with 96 wells or other types of microplate and strip |
| Reading speed |
5 seconds for a 96-well plate (single-wavelength) |
| Memory |
Storage for up to 100 programs and 10,000 sample results |
| Printer |
Internal thermal printer, optional external printer |
| Dimensions (mm) |
425 (length) x 310 (width) x 215 (height) |
| Weight |
12kg |
