Laboratory Ventilation Cleaning Fume Extraction System Hood Equipment Fume Hood YR05826 // YR05828
Laboratory Ventilation Cleaning Fume Extraction System Hood Equipment Fume Hood YR05826 // YR05828 — Kalstein laboratory equipment with technical specifications, advanced features, and certified professional solutions for scientific use.
Laboratory Ventilation Cleaning Fume Extraction System Hood Equipment Fume Hood YR05826 // YR05828 is an essential piece of equipment designed to ensure safety and efficiency in lab environments. This fume hood effectively draws in contaminated air through its front, mixing it with room air before safely expelling it via the building's exhaust system. Its construction comprises high-quality 8.0mm PP polypropylene, providing exceptional resistance to acids, alkalis, and general corrosion, making it a reliable choice for any laboratory setting. Additional features include an LCD control panel, a light-weight and corrosion-resistant PP centrifugal fan, and a movable vertical sliding window door for user protection and clear visibility.
Market Price
In the market, the average price range for high-quality lab fume hoods akin to the YR05826 // YR05828 models typically falls between $3,000 and $3,500. This price range reflects the durability, advanced features, and compliance with safety standards that are crucial for laboratory environments.
Frequently Asked Questions
- What is the warranty period for this fume hood? The product comes with a standard warranty, assuring quality and compliance. Specific terms can vary, so please contact us for details.
- Is installation included? Installation services are not included in the basic product price, but they can be coordinated separately upon request.
- Can the dimensions be customized? Yes, dimensions can be tailored according to specific customer requirements.
Advantages and Disadvantages
- Advantages: Superior corrosion resistance, customizable dimensions, efficient air management system, and enhanced safety features.
- Disadvantages: Initial setup cost can be high, and some accessories are optional and sold separately.
Product Usage in the Field
The Fume Extraction System Hood is primarily used in laboratories where hazardous chemical reactions take place, offering a controlled environment that minimizes the risk of exposure to harmful fumes. It is suitable for both educational laboratories and industrial applications, making it a versatile choice for ensuring safety and regulatory compliance.
Recommendations
To maximize the performance and longevity of your fume hood, regularly check and maintain its components, including filters, ductwork, and fans. Schedule routine inspections and ensure proper training for users on safe operational procedures. For more tailored advice or to request a quote, visit our platform, Kalstein Plus, and explore how you can optimize your laboratory with our range of products.
Features
- Multi-layered air management for effective fume extraction
- High strength and lightweight PP polypropylene construction
- Anti-corrosion and anti-acid properties
- Customizable dimensions to fit specific lab requirements
- Energy-efficient, low-noise fan system
- LCD control panel for easy operation
- Movable sliding door for enhanced safety
Technical Specifications
| Model | YR05826 | YR05827 | YR05828 |
| Notes Above size is our standard item. Dimension can be customized upon customer’s request. Built-in axial flow blower and⊄250mm exhaust duct included. | |||
| Housing | Using 8.0mm PP polypropylene plate welding production, after carving, bending the entire cabinet at one time, featured with strong anti-acid and alkali, corrosion resistance. | ||
| Inner shell | Using a new 8.0mm PP polypropylene plate welding production, with strong anti-acid and alkali, corrosion resistance characteristic, the inner side board can be fixed with water cock, gas cock. The back plate can be fixed with baffle, roof lighting and gas hood device. | ||
| Operational worktop | 8.0mm PP polypropylene worktop, includes water fender, spray-proof, the table has a good performance of waterproof, anti-acid and alkali. | ||
| Baffle | 8.0mm PP polypropylene board, resistant to strong acid and alkali. Installed in the back of the work space and above, including at least three pieces plates, so that the work space and the connection between the exhaust pipe to form a gas chamber, the polluted gas are exhausted completely, the baffle plate is attached to the cabinet with the clips, detachable. | ||
| Gas hood | PP material, with a strong corrosion resistance, rectangular opening at the bottom of the entrance, circular opening at the top | ||
| Fluorescent lamp | 1 piece 30W light (waterproof, anti-corrosion, anti-oxidation) | ||
| Window sliding door | Movable vertical pull-up door, placed between the work space and the operator to protect the operator's safety, combined with the balance position, sliding doors can be stopped at any point of activity. a piece of tempered glass window on the adjustable door, the field of view can be completely clear. | ||
| Window | Using 5mm thick tempered glass | ||
| Window frame | Aluminum alloy door frame, ensure the safety and durability of the window | ||
| Windows Suspension Cable | Plastic suspension cable, low noise, fast pulling speed, strong balance characteristic | ||
| Control switch | LCD control panel, set with the power, switches, lighting, fan and running lights and other buttons, the LCD screen can clearly show the operation of the fume hood. | ||
| Socket | Equipped with four 220V universal socket. (Other type of socket can be optional, according to customers need) | ||
| Base cabinet | 8.0mm PP polypropylene board, the door is firm solid, not easy to deformation, elegant appearance | ||
| Door handle | Laboratory PP handle, strong corrosion resistance. | ||
| Hinge | Laboratory PP hinge, strong corrosion resistance. | ||
| Water sink | PP cup , made of high-density PP ,strong corrosion resistance, with filtering and anti-odor function, water trap with high-density PP production( This is extra option) | ||
| Water cock | wall-mount remote control water valve, faucet, the main body is made of the thick copper, the surface with high brightness epoxy resin coating, corrosion resistance, heat resistance; Ceramic valve core, 90 ° rotation, life span 500,000 times, static maximum resistance Pressure 20 bar; switch knob for high-density PP production, ergonomic design, feel comfortable. (This is extra option) | ||
| Gas cock | Wall-mount remote control gas valve, the main body is made of the thick copper, the surface with high brightness epoxy resin coating, corrosion resistance, heat resistance; ergonomic design, feel comfortable. (This is extra option) | ||
| Optional Accessories | |||
| Air Velocity /Exhaust air volume requiremen | 0.4m/sec~0.6 m/sec. | ||
| Noise | ≤60dB | ||
| Blower | PP centrifugal energy-saving fan, fan motor 380V three-phase motor, fan material PP polypropylene, with high strength, light weight, not easy to aging, low noise, excellent corrosion resistance and so on. (According to the actual need, equip with the fan, duct, etc., the fume hood price does not include the fan ,duct and related accessories prices. | ||
| Dimension (L x W x H) (mm) | 1200 x 850 x 2350 | 1500 x 850 x 2350 | 1800 x 850 x 2350 |
| Weight (Kg) | 220 | 280 | 350 |
Technical specifications
| Manufacturer | Kalstein |
|---|
Available models
- Laboratory Ventilation Cleaning Fume Extraction System Hood Equipment Fume Hood YR05826 // YR05828 - YR05826 (SKU: YR05826)
- Laboratory Ventilation Cleaning Fume Extraction System Hood Equipment Fume Hood YR05826 // YR05828 - YR05827 (SKU: YR05826)
- Laboratory Ventilation Cleaning Fume Extraction System Hood Equipment Fume Hood YR05826 // YR05828 - YR05828 (SKU: YR05826)
