Description
The Doppler Fetal Monitor YR02180 is an advanced monitoring solution designed for medical professionals who require precise patient data in a variety of healthcare settings, including operating theaters and intensive care units. This semi-modular device features a comprehensive 17-inch LCD screen, displaying critical information sourced from its six essential monitoring parameters: ECG, SpO2, temperature (TEMP), non-invasive blood pressure (NIBP), respiration (RESP), and pulse rate/heart rate (PR/HR). The model stands out for its ability to offer optional enhancements, such as a touch screen interface, advanced SpO2 sensors from Masimo or Nellcor, and additional measurement capabilities like dual invasive blood pressure (IBP), cardiac output (C.O.), and bispectral index (BIS), among others.
Market Price
On average, fetal monitors of this caliber are priced between $3,500 and $4,200 USD in the market. The cost reflects the cutting-edge technology and versatile features that the Doppler Fetal Monitor YR02180 provides. Pricing varies due to differences in configurations and optional add-ons that can be tailored to the specific needs of the healthcare facility. To get a precise estimate, feel free to request a quote or explore automatic quotation options through our Kalstein Plus platform.
Frequently Asked Questions
What is the main application of the Doppler Fetal Monitor YR02180? This device is primarily used in clinical settings like operating theaters and ICUs for comprehensive patient monitoring.
Can I upgrade my existing device with additional features? Yes, the Doppler Fetal Monitor YR02180 supports various optional upgrades, including advanced sensors and modules.
Is the device easy to operate? Absolutely, it features an intuitive interface, and the optional touch screen makes navigation even simpler.
Advantages and Disadvantages
Advantages:
- Highly customizable with several optional features and modules.
- Large LCD screen for clear data visualization.
- Comprehensive monitoring parameters suitable for high-stakes environments.
Disadvantages:
- May require additional training for optimal use of advanced features.
- Initial investment can be substantial depending on the configuration.
Product Use in the Field
The Doppler Fetal Monitor YR02180 is utilized by medical professionals in critical care units to monitor a patient’s vital signs rigorously. Its real-time data display and high accuracy make it indispensable during surgeries and patient recovery, ensuring immediate response to any changes in patient conditions.
Recommendations
For optimal performance, regular calibration and maintenance of the Doppler Fetal Monitor YR02180 are recommended. Consider training staff to fully utilize optional features, which can significantly enhance monitoring capabilities and improve patient outcomes.
Features
- 17-inch LCD screen with semi-modular design.
- Standard parameters: ECG, SPO2, TEMP, NIBP, RESP, PR/HR.
- Optional upgrades like dual-IBP, advanced SpO2 analysis, and more.
- Customizable alarm settings for precise monitoring.
Technical Specifications
| Model | YR02180 | |
| ECG | Lead mode | 5 Leads(RA,LA,LL,RL,V) |
| Connection method | I, II, III,AVR,AVL,AVF,V | |
| Lead Mode | 3 Leads (RA,LA,LL) | |
| Connection method | I, II,III | |
| Gain | x250, x500, x1000, x2000 | |
| Accuracy | ±5% | |
| Resolution | 1bpm | |
| Sensitivity | >200(uVp-p) | |
| Differential input impedance | ≥5MΩ | |
| ST segment Monitoring Range | ||
| Measure Range | -1.0~+1.0mV | |
| Measure Accuracy | -0.8mV~+0.8mV | |
| Heart Rate | Measuring range | 40~240bpm |
| Accuracy | ±3bpm | |
| Resolution | 1bpm | |
| Sensitivity | >200UVp-p | |
| Respiration | Method | Impedance between R-F(RA-LL) |
| Measuring Impedance Range | 0.3~3.0 MΩ | |
| Bandwidth | 0.1~2.5Hz | |
| Respiration Rate | Adult: 7~120BrPM | |
| Neo/Ped | 7~150BrPM | |
| Resolution | 1 BrPM | |
| Accuracy | ±2 BrPM | |
| NIBP | Method | Oscillometric |
| Measuring Interval in AUTO Mode | 1,2,3,4,5,10,15,30,60,90,120,180,240(Min) | |
| Measuring Period in STAT Mode | 5 Min | |
| Pulse Rate Range | 40~240bpm / 40~150bpm | |
| Alarm Type | SYS, DIA, MEAN | |
| Resolution | ||
| Pressure | 1mmHg | |
| SPO2 | Display | Number of SPO2,waveform of capacity,Pulse |
| Measuring range | 0~100% | |
| Resolution | 1% | |
| Accuracy | 70~99% (±2%) | |
| Pulse rate range | 0~300bpm | |
| TEMP | Channel | 2 |
| Measuring and Alarm Range | 0~50ºC | |
| Resolution | 0.1ºC | |
| Accuracy | 0.1ºC | |
| Actualization interval | about 1 Second. | |
| Average Time Constant | <10 Second. | |
